NPHVL-1506-1/4-SS – Flat Nozzle, 1/4 Inlet, 303/304 Stainless Steel
Images are representative. Products may differ in material or configuration.
Images are representative. Products may differ in material or configuration.
Product Parameters
| Product Family | Flat |
|---|---|
| Product Series | NPHVL |
| Capacity Size | 6 |
| Inlet Connection Thread Type | NPT |
| Material Composition Filter | 303/304 stainless steel |
| Inlet Connection Size (in.) | 1/4 |
| Length (mm) | 38 |
| Length (in) | 1.250 |
| Hex Size (mm) | 14.3 |
| Hex Size (in) | 9/16 |
| Equivalent Orifice Diameter (in) | 0.061 |
| Spray Angle at Rated Pressure (PSI) | 15 |
| Equivalent Orifice Diameter (mm) | 1.5 |
Description
Product Overview
When dairy crews manage dust & pollution control, the NPHVL-1506-1/4-SS lets each utilities coordinator implement precise spray coverage through its flat spray pattern. Constructed from durable 303/304 stainless steel, this nozzle resists corrosion in harsh environments, ensuring consistent performance over extended service periods. Operators install the 1/4-inch inlet nozzle on cleaning rigs or ventilation systems to deliver uniform atomization, which improves particulate capture and reduces downtime caused by nozzle wear. The NPHVL-1506-1/4-SS enhances operational reliability by maintaining stable flow rates and spray angles in demanding industrial conditions.
Applications
In applications like cooling & quenching, the nozzle's flat spray provides controlled temperature regulation that protects sensitive equipment and materials. Its role in cleaning & washing extends to removing residues efficiently, leading to lower water consumption and enhanced process sanitation.
Industries
Sectors such as automotive, building materials, steel & metals, and food & beverage rely on this nozzle for its wear resistance and consistent spray distribution. The combination of corrosion resistance and precise output makes it suitable for industries ranging from mining and cement to breweries & wineries and manufactured goods assembly, where process stability and environmental control are critical.
