NPHV-11005-1/4-316 β Flat Nozzle, 1/4 Inlet, 316L stainless steel
Images are representative. Products may differ in material or configuration.
Images are representative. Products may differ in material or configuration.
Product Parameters
| Product Family | Flat |
|---|---|
| Product Series | NPHV |
| Capacity Size | 5 |
| Inlet Connection Thread Type | NPT |
| Material Composition Filter | 316L stainless steel |
| Inlet Connection Size (in.) | 1/4 |
| Length (mm) | 23 |
| Length (in) | 0.906 |
| Hex Size (mm) | 14.3 |
| Hex Size (in) | 9/16 |
| Equivalent Orifice Diameter (in) | 0.056 |
| Spray Angle at Rated Pressure (PSI) | 110 |
| Equivalent Orifice Diameter (mm) | 1.4 |
Description
Product Overview
When mining crews manage trucking & fleet wash, the NPHV-11005-1/4-316 lets each production technician deliver consistent cleaning performance by utilizing its precision flat spray pattern. Constructed from 316L stainless steel, this nozzle resists corrosion in harsh industrial environments, ensuring long service life and minimal downtime. Operators rely on the uniform distribution of fluid to optimize water or chemical use while maintaining effective coverage across vehicle surfaces. The 1/4-inch inlet supports easy integration with existing fluid delivery systems for reliable operation.
Applications
In cleaning & washing operations, the nozzle's flat spray enables thorough removal of debris and contaminants, reducing the need for repeated passes. Cooling & quenching processes benefit from the even spray pattern by controlling temperature with precise fluid coverage, improving part quality and process efficiency.
Industries
The NPHV-11005-1/4-316 is preferred across automotive, building materials, Energy, and steel & metals sectors due to its corrosion resistance and stable spray output under demanding conditions. Its versatility also meets the requirements of food & beverage and mining industries, where consistent fluid application and material durability are critical to operational continuity.
