NPHH-7.0-3/4-316 β Full Cone Nozzle, 3/4 Inlet, 316L Stainless Steel
Images are representative. Products may differ in material or configuration.
Images are representative. Products may differ in material or configuration.
Product Parameters
| Product Family | Full Cone |
|---|---|
| Product Series | NPHH |
| Capacity Size | 7 |
| Inlet Connection Thread Type | NPT |
| Material Composition Filter | 316L stainless steel |
| Orifice Diameter. Nom. (mm) | 9.5 |
| Inlet Connection Size (in.) | 3/4 |
| Length (mm) | 40.5 |
| Length (in) | 1.531 |
| Equivalent Orifice Diameter (in) | 0.328 |
| Diameter (in) | 1.063 |
| Max. Free Passage Dia. (mm) | 5.2 |
Description
Product Overview
During specialty applications on a manufacturing & assembly site, quality managers trust the NPHH-7.0-3/4-316 to deliver consistent spray coverage critical to process control. An operator installs this full cone nozzle, constructed from 316L stainless steel, to ensure corrosion resistance in harsh environments. The 3/4-inch inlet size allows for straightforward integration with existing piping systems. This nozzle produces a uniform spray pattern that enhances coating thickness uniformity and reduces material waste.
Applications
In cleaning & washing operations, the nozzle maintains steady flow rates to effectively remove contaminants without damaging sensitive surfaces. Cooling & quenching processes benefit from its precise full cone spray, which promotes even temperature distribution and improved cycle times.
Industries
The NPHH-7.0-3/4-316 is favored across automotive, building materials, and steel & metals sectors due to its durability under continuous use and resistance to corrosive agents. Its application versatility also meets the demands of Energy, food & beverage, mining, and manufacturing & assembly environments where consistent spray performance is essential.
