NPHH-3-1/8-316 β Full Cone Nozzle, 1/8 Inlet, 316L Stainless Steel
Images are representative. Products may differ in material or configuration.
Images are representative. Products may differ in material or configuration.
Product Parameters
| Product Family | Full Cone |
|---|---|
| Product Series | NPHH |
| Capacity Size | 3 |
| Inlet Connection Thread Type | NPT |
| Material Composition Filter | 316L stainless steel |
| Orifice Diameter. Nom. (mm) | 1.5 |
| Inlet Connection Size (in.) | 1/8 |
| Length (mm) | 22.2 |
| Length (in) | 0.875 |
| Equivalent Orifice Diameter (in) | 0.063 |
| Diameter (in) | 0.5 |
| Max. Free Passage Dia. (mm) | 1.0 |
Description
Product Overview
When automotive crews manage coating & surface treatment, the NPHH-3-1/8-316 lets each process engineer achieve consistent coverage through its full cone spray pattern. Constructed from 316L stainless steel, this nozzle withstands corrosive environments encountered during paint application and chemical treatments. An operator integrates the NPHH-3-1/8-316 by connecting its 1/8-inch inlet to standard piping, ensuring uniform atomization that reduces material waste and rework. This precision nozzle maintains stable flow rates critical for repeatable surface finishes in production lines.
Applications
The NPHH-3-1/8-316 is suited for cleaning & washing operations where even spray distribution removes contaminants efficiently. It is also effective in cooling & quenching scenarios, providing controlled fluid delivery that helps manage thermal loads and prevent material deformation.
Industries
Automotive, building materials, mining, and steel & metals industries rely on the durability and spray consistency of the NPHH-3-1/8-316 nozzle. These sectors benefit from its corrosion resistance and precise flow control, essential for manufacturing & assembly processes and applications within Energy and food & beverage environments.
