NPHH-14W-1/4-316 – Full Cone Nozzle, 1/4 Inlet, 316L Stainless Steel
Images are representative. Products may differ in material or configuration.
Images are representative. Products may differ in material or configuration.
Product Parameters
| Product Family | Full Cone |
|---|---|
| Product Series | NPHH |
| Capacity Size | 14W |
| Inlet Connection Thread Type | NPT |
| Material Composition Filter | 316L stainless steel |
| Orifice Diameter. Nom. (mm) | 3.6 |
| Inlet Connection Size (in.) | 1/4 |
| Length (mm) | 23 |
| Length (in) | 0.88 |
| Equivalent Orifice Diameter (in) | 0.141 |
| Max. Free Passage Dia. (mm) | 1.6 |
Description
Product Overview
A maintenance supervisor in the building materials facility uses the NPHH-14W-1/4-316 during cooling & quenching to ensure consistent temperature control on freshly processed materials. Constructed from 316l stainless steel, this nozzle delivers a uniform full cone spray pattern that minimizes hot spots and improves product integrity. Its corrosion resistance extends service life in harsh plant environments, reducing downtime for equipment replacement. The precise spray coverage also helps maintain safety standards by controlling steam and preventing overheating.
Applications
In cooling & quenching operations, the nozzle provides even fluid distribution critical for rapid temperature reduction, which enhances process efficiency. Additionally, its role in cleaning & washing removes contaminants effectively, leading to improved surface quality and preparation for further treatment.
Industries
Sectors such as automotive, mining, and steel & metals rely on the NPHH-14W-1/4-316 for its durability and consistent spray pattern under demanding conditions. The nozzle's material compatibility and performance make it a preferred choice in manufacturing & assembly as well as energy and building materials, where precise fluid application is essential.
