NPHH-10-1/4-316 – Full Cone Nozzle, 1/4 Inlet, 316L Stainless Steel
Images are representative. Products may differ in material or configuration.
Images are representative. Products may differ in material or configuration.
Product Parameters
| Product Family | Full Cone |
|---|---|
| Product Series | NPHH |
| Capacity Size | 10 |
| Inlet Connection Thread Type | NPT |
| Material Composition Filter | 316L stainless steel |
| Orifice Diameter. Nom. (mm) | 3.2 |
| Inlet Connection Size (in.) | 1/4 |
| Length (mm) | 23 |
| Length (in) | 0.880 |
| Equivalent Orifice Diameter (in) | 0.109 |
| Diameter (in) | 0.531 |
| Max. Free Passage Dia. (mm) | 1.6 |
Description
Product Overview
A utilities coordinator in the mining facility uses the NPHH-10-1/4-316 during coating & surface treatment to ensure consistent application of protective layers on metal surfaces. Constructed from 316l stainless steel, this nozzle resists corrosion in harsh environments and sustains operational integrity over extended shifts. Its precision full cone spray pattern delivers uniform coverage, minimizing material waste and improving finish quality. The 1/4 inch inlet size allows for straightforward integration into existing fluid systems, facilitating maintenance and quick replacement.
Applications
In cleaning & washing operations, the nozzle's uniform spray pattern optimizes fluid distribution, reducing cycle times and improving equipment uptime. Additionally, during cooling & quenching processes, the consistent full cone coverage enhances thermal control, which directly affects product quality and process efficiency.
Industries
Sectors such as automotive, manufacturing & assembly, and steel & metals rely on the robust corrosion resistance and spray uniformity offered by this nozzle. Energy, mining, and building materials industries also benefit from its durability and precise fluid delivery in challenging operational conditions.
