NP3U-8002-316 – ProJet 3X Modular Unit Assembly Nozzle, 316L Stainless Steel
Images are representative. Products may differ in material or configuration.
Images are representative. Products may differ in material or configuration.
Product Parameters
| Product Family | ProJet 3X Modular Unit Assembly |
|---|---|
| Product Series | NP3U |
| Capacity Size | 2 |
| Material Composition Filter | 316L stainless steel |
| Orifice Diameter. Nom. (mm) | 0..89 |
| Length (mm) | 48 |
| Hex Size (mm) | 20.6 |
| Equivalent Orifice Diameter (in) | 0.035 |
| Spray Angle at Rated Pressure (PSI) | 80 |
Description
Product Overview
A utilities coordinator in the manufacturing & assembly facility uses the NP3U-8002-316 during cooling & quenching to ensure consistent temperature control across metal components. Constructed from 316L stainless steel, the nozzle provides corrosion resistance in harsh environments while delivering a uniform spray pattern essential for even cooling rates. By integrating this modular unit assembly nozzle into the process, the operator reduces thermal stress and improves part durability, maintaining production efficiency. The precision design allows for easy maintenance and replacement within the assembly line.
Applications
In cooling & quenching operations, the NP3U-8002-316 delivers targeted spray coverage that minimizes material deformation and maintains product integrity. Additionally, its uniform spray is effective in cleaning & washing tasks, reducing residue buildup and supporting ongoing equipment maintenance.
Industries
This nozzle is widely adopted across automotive, steel & metals, and mining sectors due to its corrosion resistance and reliable spray patterns under demanding conditions. Food & beverage processing facilities and bakery & confectionery operations also utilize the NP3U-8002-316 for its sanitary materials and consistent performance in coating & surface treatment applications.
